Microwove Presence/Absence Detectors
R0,00
| CODE | TIME DELAY | DETECTION PATTERN | TRIM |
| MWS6 | 10 sec – 99 min | H: 2.8m – Ø 12-16m | White |
| Material | Flame retardant ABS and Polycarbonate/ABS |
| Features | The MWS6 is a mid-range microwave presence/absence detector for the automatic control of lighting, heating and ventilation
This detector has a low profile design which allows flush mounting into a ceiling tile, or surface mounting using a detector back box The MWS6 detects movement using a highly sensitive microwave detector The simple plug-in connections reduce installation time. The optional infrared remote handset allows the user to override the set-up Functionality is fully programmable using either the UHS5 or UNLCDHS handsets |
| Options & Accessories | Available control methods: PRM Switching, DALI / DSI Dimming, 1-10V Analogue Dimming and KNX
Functionality is fully programmable using either the optional UHS5 or UNLCDHS handsets Available options: LV – low voltage, VFC – voltage free contact, 2CH – 2 Channel and 2CH NC – 2 Channel normally closed |
| Load Rating | Incandescent = 10A
Fluorescent = 10A Compact Fluorescent = 10A LED = 10A Resistive Heaters = 10A |
| Voltage | 220-240V |
| Mounting | Recessed or Surface (with detector box) |
The MWS6 is a mid-range microwave presence/absence detector for the automatic control of lighting, heating and ventilation.
This detector has a low profile design which allows flush mounting into a ceiling tile, or surface mounting using a detector back box.
Its reduced head size makes it unobtrusive to occupants.
The MWS6 detects movement using a highly sensitive microwave detector.
The simple plug-in connections reduce installation time. The optional infrared remote handset allows the user to override the set-up.
Functionality is fully programmable using either the UHS5 or UNLCDHS handsets.
