Miniature, Retrofit, Luminaire mounted, PIR Presence Detectors
| Features | The EBMPIR-MB series of batten mount PIR presence detectors provide automatic control of lighting loads
Batten mount retrofit system, movement detection up to 9 metres high Three models are available: premium (PRM), direct dim (DD), and analogue dim (AD) all of which will switch a wide range of luminaires The direct dim variant controls DALI or DSI digital dimming ballasts, whilst the analogue dim variant controls 1–10V dimming ballasts |
| Voltage | 220-240V |
| Mounting | Surface |
| Materials | Flame retardant ABS/Polycarbonate |
| Options & Accessories | Available control methods: PRM Switching, DALI / DSI Dimming, 1-10V Analogue Dimming
Available options: LT30 – low temperature and LV – low voltage Functionality is fully programmable using either the UHS5 or UNLCDHS handsets |
| Load Rating | Incandescent = 10A
Fluorescent = 10A Compact Fluorescent = 10A LED = 10A |
| Note | Load ratings do not apply to EBMPIR-MB-DD |
The EBMPIR-MB series of batten mount PIR presence detectors provide automatic control of lighting loads.
Batten mount retrofit system, movement detection up to 9 metres high.
Three models are available: premium (PRM), direct dim (DD), and analogue dim (AD) all of which will switch a wide range of luminaires.
The direct dim variant controls DALI or DSI digital dimming ballasts, whilst the analogue dim variant controls 1–10V dimming ballasts.
