Compact PIR Presence Detectors – Remote programming
R0,00
| CODE | TIME DELAY | DETECTION PATTERN | TRIM |
| EBDSM | 10 sec – 99 min | H: 2.8m – Ø 7m | White |
| Material | Flame retardant ABS and Polycarbonate/ABS |
| Features | These compact surface mounted PIR detectors provide automatic control for lighting, heating and ventilation loads No external control boxes are required as the unit is self contained This range of surface mounted PIR presence detectors is perfect for simple attachment when flush mounting is not possible Self contained unit, Easy to install via back plate Infrared programmable via our UHS5 and UNLCDHS handsets IP40 without gasket; IP54 with gasket |
| Options & Accessories | Three models are available: premium (PRM), direct dim (DD), and analogue dim (AD) all of which will switch a wide range of luminaires The direct dim variant controls DALI or DSI digital dimming ballasts whilst the analogue dim variant controls 1–10V dimming ballasts UHS5 and UNLCDHS handsets available for selection |
| Load Rating | Incandescent = 10A Fluorescent = 10A Compact Fluorescent = 10A LED = 10A Resistive Heaters = 10A Fans & Ventilation = 10A |
| Voltage | 220-240V |
| Mounting | Surface |
