Twilight Photocell Switch
R0,00
| CODE | TIME DELAY | DETECTION PATTERN | TRIM |
| ALC15 | 0 min – 16 hrs | Ambient light sensing | White |
| Material | Polystyrene casing |
| Features | The ALC15 twilight switch will turn lighting on when the ambient light falls below a preset level The lighting will then be turned off when the light exceeds the preset level or after a preset time delay – For example, they can be used to switch external security lights at night or to turn on display or sign lighting The unit has a highly accurate adjustable photocell; a selectable time delay; adjustable switching differential and is mounted in a vandal resistant IP66 enclosure Works with any type of lamp Adjust time delay and lux settings via pots> |
| Load Rating at 230VAC | Incandescent = 8A Fluorescent = 6A Compact Fluorescent = 3A LED = 3A Resistive Heaters = 10A |
| Voltage | 220-240V |
| Mounting | Surface |
